P27D6-1PHASE-60Hz Diesel Generator

Engineered for precision, reliability, and peace of mind—fully designed, assembled, and tested in ISO9001-certified facilities.

🔋 Power Ratings & Reliability

The P27D6-1PHASE-60Hz generator is built for dependable standby and prime power applications. Whether you’re protecting your home, business, or critical infrastructure, this unit delivers consistent performance with global support.

• Phase: Single-phase
• Frequency: 60Hz
• Engine: Perkins 404D-22G, 1800RPM, turbocharged
• Governor: Electronic isochronous for precise speed control
• Cooling System: Industrial-grade with fan guards and coolant drain extension

⚙️ Premium Alternator

At the heart of the P27D6 is the Leroy Somer LSA42.3S4 alternator—engineered for clean, stable power output and long-term durability.

• 12-lead brushless design
• Thermo-magnetic switch protection
• Skewed rotor and 2/3 pitch winding for harmonic suppression
• Class H insulation with drip-proof, self-ventilated housing
• Electronic automatic voltage regulation (AVR)

🧠 Advanced Digital Controller

Control and monitor your generator with the Deep Sea Electronics DSE4520 controller—UL listed and packed with smart features.

• Microprocessor-based with dual-core processing and extended memory
• Large 4-line backlit LCD display with multilingual support
• Manual, Test, and Auto modes with 2-wire remote start/stop
• 250-event history log and 50+ configurable alarms
• Automatic shutdowns for voltage, frequency, speed, temperature, oil pressure, and coolant level

⛽ Fuel System & Runtime

Equipped with a 15-gallon single-walled metallic fuel tank, the P27D6 offers extended autonomy and intelligent fuel monitoring.

• 13 hours runtime @ 75% PRP
• 10 hours runtime @ 100% PRP
• Electronic fuel level sender and visual gauge
• Programmable low/high-level alarms and shutdowns

🔩 Packaged for Versatility

This generator is fully packaged and ready for most standby and prime power applications, with rugged construction and smart layout.

• 7-gauge heavy-duty welded steel skid
• Compartmentalized master cabinet for control, power, and breaker components
• Main line breaker, 3-pole, set-mounted and wired
• Heavy-duty AVMs isolate engine, radiator, and alternator from frame
• Electrolyte-charged battery with rack, cables, and rubber-booted terminals
• Oil drain extension with in-line valve

✅ Engineered for Excellence

• Each unit load-bank tested in ISO9001-certified facilities
• International warranty: 2 years or 2000 hours (T&C apply)
• Accepts 100% rated load in one step (NFPA110 compliant)
• Meets ISO8528-5 class G-2 for transient response
• Compliant with ISO, EN, NEMA, NEC, and IEC standards
• NFPA 37 and NFPA Type 10 Level 1 capable (with accessories)

📦 What’s Included

• P27D6 Generator Unit
• Perkins Engine & Leroy Somer Alternator
• DSE4520 Digital Controller
• 15-Gal Fuel Tank
• Battery, filters, silencer, and manuals

📞 Order Now

Static Pulse Electrical offers full-service generator imports and installation across The Bahamas. Contact us today to secure your P27D6 and enjoy reliable power with expert support.

Phone: +1 242 326 1222 / +1 242 807 9194
Email: contact@powerglowelectrical.com
